MultiListBox properties. MultiListBox_skin_childs Skin childs. MultiListBox widget description should be here. More...

#include <MyGUI_MultiListBox.h>

Inheritance diagram for MyGUI::MultiListBox:

Public Types
typedef RTTIBase	Base

typedef MultiListBox	RTTIBase

Public Types inherited from MyGUI::Widget
typedef RTTIBase	Base

typedef Widget	RTTIBase

Public Types inherited from MyGUI::IObject
typedef IObject	RTTIBase

Public Member Functions
virtual const std::string &	getTypeName () const

virtual bool	isType (const std::type_info &_type) const

template<typename Type >
bool	isType () const

	MultiListBox ()

virtual void	setPosition (const IntPoint &_value)
	More...

virtual void	setSize (const IntSize &_value)
	More...

virtual void	setCoord (const IntCoord &_value)
	More...

void	setPosition (int _left, int _top)
	More...

void	setSize (int _width, int _height)
	More...

void	setCoord (int _left, int _top, int _width, int _height)
	More...

size_t	getColumnCount () const
	Get number of columns. More...

void	insertColumnAt (size_t _column, const UString &_name, int _width=0, Any _data=Any::Null)

void	addColumn (const UString &_name, int _width=0, Any _data=Any::Null)

void	removeColumnAt (size_t _column)

void	removeAllColumns ()

void	swapColumnsAt (size_t _index1, size_t _index2)
	Swap columns at a specified positions. More...

void	setColumnNameAt (size_t _column, const UString &_name)

void	setColumnName (MultiListItem *_item, const UString &_name)

void	setColumnWidthAt (size_t _column, int _width)

void	setColumnWidth (MultiListItem *_item, int _width)

const UString &	getColumnNameAt (size_t _column)

const UString &	getColumnName (MultiListItem *_item)

int	getColumnWidthAt (size_t _column)

void	sortByColumn (size_t _column, bool _backward=false)

size_t	getColumnIndex (MultiListItem *_item)
	Get column index. More...

void	setColumnResizingPolicy (MultiListItem *_item, ResizingPolicy _value)

void	setColumnResizingPolicyAt (size_t _index, ResizingPolicy _value)

void	setColumnDataAt (size_t _index, Any _data)
	Replace an item data at a specified position. More...

void	clearColumnDataAt (size_t _index)
	Clear an item data at a specified position. More...

template<typename ValueType >
ValueType *	getColumnDataAt (size_t _index, bool _throw=true)
	Get item data from specified position. More...

size_t	getItemCount () const

void	insertItemAt (size_t _index, const UString &_name, Any _data=Any::Null)

void	addItem (const UString &_name, Any _data=Any::Null)

void	removeItemAt (size_t _index)
	Remove item at a specified position. More...

void	removeAllItems ()

void	swapItemsAt (size_t _index1, size_t _index2)
	Swap items at a specified positions. More...

void	setItemNameAt (size_t _index, const UString &_name)
	Replace an item name. More...

const UString &	getItemNameAt (size_t _index)
	Get item name from specified position. More...

size_t	getIndexSelected () const

void	setIndexSelected (size_t _index)

void	clearIndexSelected ()

void	setItemDataAt (size_t _index, Any _data)
	Replace an item data at a specified position. More...

void	clearItemDataAt (size_t _index)
	Clear an item data at a specified position. More...

template<typename ValueType >
ValueType *	getItemDataAt (size_t _index, bool _throw=true)
	Get item data from specified position. More...

void	setSubItemNameAt (size_t _column, size_t _index, const UString &_name)

const UString &	getSubItemNameAt (size_t _column, size_t _index)

size_t	findSubItemWith (size_t _column, const UString &_name)

void	setSubItemDataAt (size_t _column, size_t _index, Any _data)
	Replace an item data at a specified position. More...

void	clearSubItemDataAt (size_t _column, size_t _index)
	Clear an item data at a specified position. More...

template<typename ValueType >
ValueType *	getSubItemDataAt (size_t _column, size_t _index, bool _throw=true)
	Get item data from specified position. More...

virtual size_t	_getItemCount ()

virtual void	_addItem (const MyGUI::UString &_name)

virtual void	_removeItemAt (size_t _index)

virtual Widget *	_getItemAt (size_t _index)

virtual void	_setItemNameAt (size_t _index, const UString &_name)

virtual const UString &	_getItemNameAt (size_t _index)

Public Member Functions inherited from MyGUI::Widget
template<typename Type >
bool	isType () const

	Widget ()

Widget *	createWidgetT (const std::string &_type, const std::string &_skin, const IntCoord &_coord, Align _align, const std::string &_name="")

Widget *	createWidgetT (const std::string &_type, const std::string &_skin, int _left, int _top, int _width, int _height, Align _align, const std::string &_name="")

Widget *	createWidgetRealT (const std::string &_type, const std::string &_skin, const FloatCoord &_coord, Align _align, const std::string &_name="")

Widget *	createWidgetRealT (const std::string &_type, const std::string &_skin, float _left, float _top, float _width, float _height, Align _align, const std::string &_name="")

template<typename T >
T *	createWidget (const std::string &_skin, const IntCoord &_coord, Align _align, const std::string &_name="")

template<typename T >
T *	createWidget (const std::string &_skin, int _left, int _top, int _width, int _height, Align _align, const std::string &_name="")

template<typename T >
T *	createWidgetReal (const std::string &_skin, const FloatCoord &_coord, Align _align, const std::string &_name="")

template<typename T >
T *	createWidgetReal (const std::string &_skin, float _left, float _top, float _width, float _height, Align _align, const std::string &_name="")

Widget *	createWidgetT (WidgetStyle _style, const std::string &_type, const std::string &_skin, const IntCoord &_coord, Align _align, const std::string &_layer="", const std::string &_name="")

template<typename T >
T *	createWidget (WidgetStyle _style, const std::string &_skin, const IntCoord &_coord, Align _align, const std::string &_layer="", const std::string &_name="")

void	setPosition (int _left, int _top)

void	setSize (int _width, int _height)

void	setCoord (int _left, int _top, int _width, int _height)

void	setRealPosition (const FloatPoint &_value)

void	setRealSize (const FloatSize &_value)

void	setRealCoord (const FloatCoord &_value)

void	setRealPosition (float _left, float _top)

void	setRealSize (float _width, float _height)

void	setRealCoord (float _left, float _top, float _width, float _height)

const std::string &	getName () const
	Get name of widget. More...

virtual void	setVisible (bool _value)

bool	getVisible () const

void	setDepth (int _value)

int	getDepth () const

bool	getInheritedVisible () const

virtual void	setAlign (Align _value)

Align	getAlign () const

void	setAlpha (float _value)

float	getAlpha () const

void	setInheritsAlpha (bool _value)

bool	getInheritsAlpha () const

void	setColour (const Colour &_value)

bool	isRootWidget () const

Widget *	getParent () const

IntSize	getParentSize () const

EnumeratorWidgetPtr	getEnumerator () const

size_t	getChildCount ()

Widget *	getChildAt (size_t _index)

Widget *	findWidget (const std::string &_name)

void	findWidgets (const std::string &_name, VectorWidgetPtr &_result)

virtual void	setEnabled (bool _value)

void	setEnabledSilent (bool _value)

bool	getEnabled () const

bool	getInheritedEnabled () const

IntCoord	getClientCoord ()

Widget *	getClientWidget ()

void	detachFromWidget (const std::string &_layer="")

void	attachToWidget (Widget *_parent, WidgetStyle _style=WidgetStyle::Child, const std::string &_layer="")

void	changeWidgetSkin (const std::string &_skinName)

void	setWidgetStyle (WidgetStyle _style, const std::string &_layer="")

WidgetStyle	getWidgetStyle () const

void	setProperty (const std::string &_key, const std::string &_value)

virtual size_t	_getItemIndex (Widget *_item)

void	_forcePick (Widget *_widget)

void	_initialise (WidgetStyle _style, const IntCoord &_coord, const std::string &_skinName, Widget _parent, ICroppedRectangle _croppedParent, const std::string &_name)

void	_shutdown ()

void	_destroyChildWidget (Widget *_widget)

void	_setContainer (Widget *_value)

Widget *	_getContainer ()

void	_setAlign (const IntSize &_oldsize, const IntSize &_newSize)

bool	_checkPoint (int _left, int _top) const

Widget *	_createSkinWidget (WidgetStyle _style, const std::string &_type, const std::string &_skin, const IntCoord &_coord, Align _align, const std::string &_layer="", const std::string &_name="")

virtual void	_resetContainer (bool _update)

bool	_setWidgetState (const std::string &_value)

void	_updateChilds ()

Public Member Functions inherited from MyGUI::IObject
template<typename Type >
bool	isType () const

template<typename Type >
Type *	castType (bool _throw=true)

template<typename Type >
const Type *	castType (bool _throw=true) const

	IObject ()

virtual	~IObject ()

Public Member Functions inherited from MyGUI::ICroppedRectangle
	ICroppedRectangle ()

virtual	~ICroppedRectangle ()

ICroppedRectangle *	getCroppedParent ()

IntPoint	getPosition () const

IntSize	getSize () const

const IntCoord &	getCoord () const

const IntPoint &	getAbsolutePosition () const

IntRect	getAbsoluteRect () const

IntCoord	getAbsoluteCoord () const

int	getAbsoluteLeft () const

int	getAbsoluteTop () const

int	getLeft () const

int	getRight () const

int	getTop () const

int	getBottom () const

int	getWidth () const

int	getHeight () const

bool	_isMargin () const

int	_getViewLeft () const

int	_getViewRight () const

int	_getViewTop () const

int	_getViewBottom () const

int	_getViewWidth () const

int	_getViewHeight () const

void	_setCroppedParent (ICroppedRectangle *_parent)

const IntRect &	_getMargin () const

int	_getMarginLeft () const

int	_getMarginRight () const

int	_getMarginTop () const

int	_getMarginBottom () const

Public Member Functions inherited from MyGUI::UserData
	UserData ()

virtual	~UserData ()

void	setUserString (const std::string &_key, const std::string &_value)

const std::string &	getUserString (const std::string &_key) const

const MapString &	getUserStrings () const

bool	clearUserString (const std::string &_key)

bool	isUserString (const std::string &_key) const

void	clearUserStrings ()

void	setUserData (Any _data)

template<typename ValueType >
ValueType *	getUserData (bool _throw=true) const

void	_setInternalData (Any _data)

template<typename ValueType >
ValueType *	_getInternalData (bool _throw=true) const

Public Member Functions inherited from MyGUI::WidgetInput
	WidgetInput ()

virtual	~WidgetInput ()

void	setNeedToolTip (bool _value)

bool	getNeedToolTip () const

void	setPointer (const std::string &_value)

const std::string &	getPointer () const

void	setNeedKeyFocus (bool _value)

bool	getNeedKeyFocus () const

void	setNeedMouseFocus (bool _value)

bool	getNeedMouseFocus () const

void	setInheritsPick (bool _value)

bool	getInheritsPick () const

void	setMaskPick (const std::string &_filename)

void	setMaskPick (const MaskPickInfo &_info)

bool	isMaskPickInside (const IntPoint &_point, const IntCoord &_coord) const

bool	getRootMouseFocus () const

bool	getRootKeyFocus () const

void	_riseMouseLostFocus (Widget *_new)

void	_riseMouseSetFocus (Widget *_old)

void	_riseMouseDrag (int _left, int _top, MouseButton _id)

void	_riseMouseMove (int _left, int _top)

void	_riseMouseWheel (int _rel)

void	_riseMouseButtonPressed (int _left, int _top, MouseButton _id)

void	_riseMouseButtonReleased (int _left, int _top, MouseButton _id)

void	_riseMouseButtonClick ()

void	_riseMouseButtonDoubleClick ()

void	_riseKeyLostFocus (Widget *_new)

void	_riseKeySetFocus (Widget *_old)

void	_riseKeyButtonPressed (KeyCode _key, Char _char)

void	_riseKeyButtonReleased (KeyCode _key)

void	_riseMouseChangeRootFocus (bool _focus)

void	_riseKeyChangeRootFocus (bool _focus)

void	_setRootMouseFocus (bool _value)

void	_setRootKeyFocus (bool _value)

Public Member Functions inherited from MyGUI::delegates::IDelegateUnlink
virtual	~IDelegateUnlink ()

	IDelegateUnlink ()

bool	compare (IDelegateUnlink *_unlink) const

Public Member Functions inherited from MyGUI::SkinItem
	SkinItem ()

ISubWidgetText *	getSubWidgetText ()

ISubWidgetRect *	getSubWidgetMain ()

void	_setTextureName (const std::string &_texture)

const std::string &	_getTextureName () const

Public Member Functions inherited from MyGUI::LayerItem
	LayerItem ()

virtual	~LayerItem ()

ILayer *	getLayer () const

ILayerNode *	getLayerNode () const

virtual void	attachItemToNode (ILayer _layer, ILayerNode _node)

virtual void	detachFromLayer ()

virtual void	upLayerItem ()

void	setRenderItemTexture (ITexture *_texture)

void	addChildItem (LayerItem *_item)

void	removeChildItem (LayerItem *_item)

void	addChildNode (LayerItem *_item)

void	removeChildNode (LayerItem *_item)

void	addRenderItem (ISubWidget *_item)

void	removeAllRenderItems ()

void	saveLayerItem ()

void	restoreLayerItem ()

Public Member Functions inherited from MyGUI::ILayerItem
virtual	~ILayerItem ()

Public Member Functions inherited from MyGUI::MemberObsolete< Widget >
bool	isEnabled ()

bool	isInheritsAlpha ()

bool	isNeedKeyFocus ()

bool	isNeedMouseFocus ()

bool	isInheritsPick ()

bool	isVisible ()

Public Member Functions inherited from MyGUI::BiIndexBase
	BiIndexBase ()

virtual	~BiIndexBase ()

Public Member Functions inherited from MyGUI::IItemContainer
	IItemContainer ()

virtual	~IItemContainer ()

virtual void	_setItemSelected (IItem *_item)

Public Member Functions inherited from MyGUI::MemberObsolete< MultiListBox >
size_t	getItemIndexSelected ()

void	setItemSelectedAt (size_t _index)

void	clearItemSelected ()

size_t	findItem (size_t _column, const UString &_name)

const UString &	getSubItem (size_t _column, size_t _index)

void	setSubItem (size_t _column, size_t _index, const UString &_name)

void	deleteColumn (size_t _column)

void	deleteAllColumns ()

int	getColumnWidth (size_t _column)

const UString &	getColumnName (size_t _column)

void	setColumnWidth (size_t _column, int _width)

void	addColumn (int _width, const UString &_name)

void	setColumnName (size_t _column, const UString &_name)

void	insertColumn (size_t _column, int _width, const UString &_name)

size_t	getItemSelect ()

void	resetItemSelect ()

void	setItemSelect (size_t _index)

void	insertItem (size_t _index, const UString &_name)

void	setItem (size_t _index, const UString &_name)

const UString &	getItem (size_t _index)

void	deleteItem (size_t _index)

void	deleteAllItems ()

Static Public Member Functions
static const std::string &	getClassTypeName ()

Static Public Member Functions inherited from MyGUI::Widget
static const std::string &	getClassTypeName ()

Static Public Member Functions inherited from MyGUI::IObject
static const std::string &	getClassTypeName ()

Data Fields
EventPair < EventHandle_WidgetSizeT, EventHandle_MultiListPtrSizeT >	eventListSelectAccept

EventPair < EventHandle_WidgetSizeT, EventHandle_MultiListPtrSizeT >	eventListChangePosition

EventHandle_MultiListPtrSizeTCUTFStringRefCUTFStringRefBoolRef	requestOperatorLess

Data Fields inherited from MyGUI::Widget
EventHandle_WidgetStringString	eventChangeProperty

EventHandle_WidgetVoid	eventChangeCoord

Data Fields inherited from MyGUI::WidgetInput
EventHandle_WidgetWidget	eventMouseLostFocus

EventHandle_WidgetWidget	eventMouseSetFocus

EventPairAddParameter < EventHandle_WidgetIntInt, EventHandle_WidgetIntIntButton >	eventMouseDrag

EventHandle_WidgetIntInt	eventMouseMove

EventHandle_WidgetInt	eventMouseWheel

EventHandle_WidgetIntIntButton	eventMouseButtonPressed

EventHandle_WidgetIntIntButton	eventMouseButtonReleased

EventHandle_WidgetVoid	eventMouseButtonClick

EventHandle_WidgetVoid	eventMouseButtonDoubleClick

EventHandle_WidgetWidget	eventKeyLostFocus

EventHandle_WidgetWidget	eventKeySetFocus

EventHandle_WidgetKeyCodeChar	eventKeyButtonPressed

EventHandle_WidgetKeyCode	eventKeyButtonReleased

EventHandle_WidgetBool	eventRootMouseChangeFocus

EventHandle_WidgetBool	eventRootKeyChangeFocus

EventHandle_WidgetToolTip	eventToolTip

Protected Member Functions
virtual void	initialiseOverride ()

virtual void	shutdownOverride ()

virtual void	onWidgetCreated (Widget *_widget)

virtual void	onWidgetDestroy (Widget *_widget)

Protected Member Functions inherited from MyGUI::Widget
virtual	~Widget ()

void	_updateView ()

Widget *	baseCreateWidget (WidgetStyle _style, const std::string &_type, const std::string &_skin, const IntCoord &_coord, Align _align, const std::string &_layer, const std::string &_name, bool _template)

void	_destroyAllChildWidget ()

virtual size_t	_getContainerIndex (const IntPoint &_point)

virtual void	baseUpdateEnable ()

virtual ILayerItem *	getLayerItemByPoint (int _left, int _top) const

virtual const IntCoord &	getLayerItemCoord () const

template<typename T >
void	assignWidget (T *&_widget, const std::string &_name)

VectorWidgetPtr	getSkinWidgetsByName (const std::string &_name)

void	destroySkinWidget (Widget *_widget)

void	setWidgetClient (Widget *_widget)

virtual void	setPropertyOverride (const std::string &_key, const std::string &_value)

Protected Member Functions inherited from MyGUI::ICroppedRectangle
bool	_checkMargin ()

bool	_checkOutside () const

Protected Member Functions inherited from MyGUI::WidgetInput
virtual void	onMouseLostFocus (Widget *_new)

virtual void	onMouseSetFocus (Widget *_old)

virtual void	onMouseDrag (int _left, int _top, MouseButton _id)

virtual void	onMouseMove (int _left, int _top)

virtual void	onMouseWheel (int _rel)

virtual void	onMouseButtonPressed (int _left, int _top, MouseButton _id)

virtual void	onMouseButtonReleased (int _left, int _top, MouseButton _id)

virtual void	onMouseButtonClick ()

virtual void	onMouseButtonDoubleClick ()

virtual void	onKeyLostFocus (Widget *_new)

virtual void	onKeySetFocus (Widget *_old)

virtual void	onKeyButtonPressed (KeyCode _key, Char _char)

virtual void	onKeyButtonReleased (KeyCode _key)

virtual void	onMouseChangeRootFocus (bool _focus)

virtual void	onKeyChangeRootFocus (bool _focus)

Protected Member Functions inherited from MyGUI::SkinItem
void	_createSkinItem (ResourceSkin *_info)

void	_deleteSkinItem ()

void	_setSkinItemAlign (const IntSize &_size)

void	_setSkinItemVisible (bool _value)

void	_setSkinItemColour (const Colour &_value)

void	_setSkinItemAlpha (float _value)

void	_correctSkinItemView ()

void	_updateSkinItemView ()

bool	_setSkinItemState (const std::string &_state)

void	_setSubSkinVisible (bool _visible)

Protected Member Functions inherited from MyGUI::LayerItem
void	attachToLayerItemNode (ILayerNode *_node, bool _deep)

void	detachFromLayerItemNode (bool _deep)

Protected Member Functions inherited from MyGUI::BiIndexBase
size_t	getIndexCount () const

size_t	insertItemAt (size_t _index)

size_t	removeItemAt (size_t _index)

void	removeAllItems ()

size_t	convertToBack (size_t _index) const

size_t	convertToFace (size_t _index) const

void	swapItemsFaceAt (size_t _index1, size_t _index2)

void	swapItemsBackAt (size_t _index1, size_t _index2)

Additional Inherited Members
Protected Attributes inherited from MyGUI::ICroppedRectangle
IntRect	mMargin

IntCoord	mCoord

IntPoint	mAbsolutePosition

bool	mIsMargin

ICroppedRectangle *	mCroppedParent

Detailed Description

MultiListBox properties. MultiListBox_skin_childs Skin childs. MultiListBox widget description should be here.

Definition at line 32 of file MyGUI_MultiListBox.h.

Member Typedef Documentation

typedef RTTIBase MyGUI::MultiListBox::Base

Definition at line 38 of file MyGUI_MultiListBox.h.

typedef MultiListBox MyGUI::MultiListBox::RTTIBase

Definition at line 38 of file MyGUI_MultiListBox.h.

Constructor & Destructor Documentation

MyGUI::MultiListBox::MultiListBox ( )

Definition at line 20 of file MyGUI_MultiListBox.cpp.

Member Function Documentation

void MyGUI::MultiListBox::_addItem ( const MyGUI::UString & _name )

virtual

Reimplemented from MyGUI::IItemContainer.

Definition at line 580 of file MyGUI_MultiListBox.cpp.

Widget * MyGUI::MultiListBox::_getItemAt ( size_t _index )

virtual

Reimplemented from MyGUI::IItemContainer.

Definition at line 763 of file MyGUI_MultiListBox.cpp.

size_t MyGUI::MultiListBox::_getItemCount ( )

virtual

Reimplemented from MyGUI::IItemContainer.

Definition at line 575 of file MyGUI_MultiListBox.cpp.

const UString & MyGUI::MultiListBox::_getItemNameAt ( size_t _index )

virtual

Reimplemented from MyGUI::IItemContainer.

Definition at line 596 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::_removeItemAt ( size_t _index )

virtual

Reimplemented from MyGUI::IItemContainer.

Definition at line 586 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::_setItemNameAt	(	size_t	_index,
		const UString &	_name
	)

virtual

Reimplemented from MyGUI::IItemContainer.

Definition at line 591 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::addColumn	(	const UString &	_name,
		int	_width = `0`,
		Any	_data = `Any::Null`
	)

Add new column at last position

Parameters

_width	Width of new column
_name	Name of new column
_data	Any data associated with new column

Definition at line 519 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::addItem	(	const UString &	_name,
		Any	_data = `Any::Null`
	)

Add new item at the end

Definition at line 529 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::clearColumnDataAt ( size_t _index )

Clear an item data at a specified position.

Definition at line 524 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::clearIndexSelected ( )

Clear item selection

Definition at line 549 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::clearItemDataAt ( size_t _index )

Clear an item data at a specified position.

Definition at line 559 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::clearSubItemDataAt	(	size_t	_column,
		size_t	_index
	)

Clear an item data at a specified position.

Definition at line 564 of file MyGUI_MultiListBox.cpp.

size_t MyGUI::MultiListBox::findSubItemWith	(	size_t	_column,
		const UString &	_name
	)

Search item in specified _column, returns index of the first occurrence in column or ITEM_NONE if item not found

Definition at line 216 of file MyGUI_MultiListBox.cpp.

static const std::string& MyGUI::MultiListBox::getClassTypeName ( )

inlinestatic

Definition at line 38 of file MyGUI_MultiListBox.h.

size_t MyGUI::MultiListBox::getColumnCount ( ) const

Get number of columns.

Definition at line 514 of file MyGUI_MultiListBox.cpp.

template<typename ValueType >

ValueType* MyGUI::MultiListBox::getColumnDataAt	(	size_t	_index,
		bool	_throw = `true`
	)

inline

Get item data from specified position.

Definition at line 153 of file MyGUI_MultiListBox.h.

size_t MyGUI::MultiListBox::getColumnIndex ( MultiListItem * _item )

Get column index.

Definition at line 779 of file MyGUI_MultiListBox.cpp.

const UString & MyGUI::MultiListBox::getColumnName ( MultiListItem * _item )

Get _column name

Definition at line 774 of file MyGUI_MultiListBox.cpp.

const UString & MyGUI::MultiListBox::getColumnNameAt ( size_t _column )

Get _column name

Definition at line 109 of file MyGUI_MultiListBox.cpp.

int MyGUI::MultiListBox::getColumnWidthAt ( size_t _column )

Get _column width

Definition at line 115 of file MyGUI_MultiListBox.cpp.

size_t MyGUI::MultiListBox::getIndexSelected ( ) const

Get index of selected item (ITEM_NONE if none selected)

Definition at line 544 of file MyGUI_MultiListBox.cpp.

size_t MyGUI::MultiListBox::getItemCount ( ) const

Note: All indexes used here is indexes of unsorted Multilist. Even if you sorted it - all items indexes will be same as before sort.Get number of items (lines)

Definition at line 148 of file MyGUI_MultiListBox.cpp.

template<typename ValueType >

ValueType* MyGUI::MultiListBox::getItemDataAt	(	size_t	_index,
		bool	_throw = `true`
	)

inline

Get item data from specified position.

Definition at line 222 of file MyGUI_MultiListBox.h.

const UString & MyGUI::MultiListBox::getItemNameAt ( size_t _index )

Get item name from specified position.

Definition at line 539 of file MyGUI_MultiListBox.cpp.

template<typename ValueType >

ValueType* MyGUI::MultiListBox::getSubItemDataAt	(	size_t	_column,
		size_t	_index,
		bool	_throw = `true`
	)

inline

Get item data from specified position.

Definition at line 257 of file MyGUI_MultiListBox.h.

const UString & MyGUI::MultiListBox::getSubItemNameAt	(	size_t	_column,
		size_t	_index
	)

Get sub item name

Definition at line 208 of file MyGUI_MultiListBox.cpp.

virtual const std::string& MyGUI::MultiListBox::getTypeName ( ) const

inlinevirtual

Get type name as string

Reimplemented from MyGUI::Widget.

Definition at line 38 of file MyGUI_MultiListBox.h.

void MyGUI::MultiListBox::initialiseOverride ( )

protectedvirtual

skin clilds:: HeaderPlace is child widget with type Widget. Место для заголовков колонок.

skin clilds:: Client is child widget with type Widget. Клиентская зона.

skin clilds:: Empty is child widget with type Widget. Виджет для заголовка в месте где нет списков.

Reimplemented from MyGUI::Widget.

Definition at line 35 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::insertColumnAt	(	size_t	_column,
		const UString &	_name,
		int	_width = `0`,
		Any	_data = `Any::Null`
	)

Insert new column

Parameters

_column	New column will be inserted before _column
_name	Name of new column
_width	Width of new column
_data	Any data associated with new column

Definition at line 601 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::insertItemAt	(	size_t	_index,
		const UString &	_name,
		Any	_data = `Any::Null`
	)

Insert new item before _index line

Definition at line 436 of file MyGUI_MultiListBox.cpp.

template<typename Type >

bool MyGUI::MultiListBox::isType ( ) const

inline

Compare with selected type

Definition at line 38 of file MyGUI_MultiListBox.h.

virtual bool MyGUI::MultiListBox::isType ( const std::type_info & _type ) const

inlinevirtual

Compare with selected type

Reimplemented from MyGUI::Widget.

Definition at line 38 of file MyGUI_MultiListBox.h.

void MyGUI::MultiListBox::onWidgetCreated ( Widget * _widget )

protectedvirtual

Reimplemented from MyGUI::Widget.

Definition at line 659 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::onWidgetDestroy ( Widget * _widget )

protectedvirtual

Reimplemented from MyGUI::Widget.

Definition at line 670 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::removeAllColumns ( )

Delete all columns

Definition at line 121 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::removeAllItems ( )

Delete all items

Definition at line 155 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::removeColumnAt ( size_t _column )

Delete column

Definition at line 627 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::removeItemAt ( size_t _index )

Remove item at a specified position.

Definition at line 461 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setColumnDataAt	(	size_t	_index,
		Any	_data
	)

Replace an item data at a specified position.

Definition at line 500 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setColumnName	(	MultiListItem *	_item,
		const UString &	_name
	)

Set column name

Parameters

_item	column
_name	New name of column

Definition at line 769 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setColumnNameAt	(	size_t	_column,
		const UString &	_name
	)

Set column name

Parameters

_column	Index of column
_name	New name of column

Definition at line 93 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setColumnResizingPolicy	(	MultiListItem *	_item,
		ResizingPolicy	_value
	)

Set resizing policy of column.

See Also: ResizingPolicy

Parameters

_item	Pointer to column
_value	New resizing policy for column

Definition at line 790 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setColumnResizingPolicyAt	(	size_t	_index,
		ResizingPolicy	_value
	)

Set resizing policy of column.

See Also: ResizingPolicy

Parameters

_index	Index of column
_value	New resizing policy for column

Definition at line 795 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setColumnWidth	(	MultiListItem *	_item,
		int	_width
	)

Set column width

Parameters

_item	column
_width	New width of column

Definition at line 802 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setColumnWidthAt	(	size_t	_column,
		int	_width
	)

Set column width

Parameters

_column	Index of column
_width	New width of column

Definition at line 102 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setCoord ( const IntCoord & _value )

virtual

Set widget position and size

Reimplemented from MyGUI::Widget.

Definition at line 820 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setCoord	(	int	_left,
		int	_top,
		int	_width,
		int	_height
	)

See Widget::setCoord(const IntCoord& _coord)

Definition at line 838 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setIndexSelected ( size_t _index )

Select specified _index

Definition at line 184 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setItemDataAt	(	size_t	_index,
		Any	_data
	)

Replace an item data at a specified position.

Definition at line 554 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setItemNameAt	(	size_t	_index,
		const UString &	_name
	)

Replace an item name.

Definition at line 534 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setPosition ( const IntPoint & _value )

virtual

Set widget position (position of left top corner)

Reimplemented from MyGUI::Widget.

Definition at line 807 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setPosition	(	int	_left,
		int	_top
	)

See Widget::setPosition(const IntPoint& _pos)

Definition at line 828 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setSize ( const IntSize & _value )

virtual

Set widget size

Reimplemented from MyGUI::Widget.

Definition at line 812 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setSize	(	int	_width,
		int	_height
	)

See Widget::setSize(const IntSize& _size)

Definition at line 833 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setSubItemDataAt	(	size_t	_column,
		size_t	_index,
		Any	_data
	)

Replace an item data at a specified position.

Definition at line 506 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::setSubItemNameAt	(	size_t	_column,
		size_t	_index,
		const UString &	_name
	)

Set sub item

Parameters

_column	Index of column
_index	Index of line
_name	New sub item value

Definition at line 196 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::shutdownOverride ( )

protectedvirtual

Reimplemented from MyGUI::Widget.

Definition at line 86 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::sortByColumn	(	size_t	_column,
		bool	_backward = `false`
	)

Sort multilist by column

Definition at line 127 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::swapColumnsAt	(	size_t	_index1,
		size_t	_index2
	)

Swap columns at a specified positions.

Definition at line 636 of file MyGUI_MultiListBox.cpp.

void MyGUI::MultiListBox::swapItemsAt	(	size_t	_index1,
		size_t	_index2
	)

Swap items at a specified positions.

Definition at line 487 of file MyGUI_MultiListBox.cpp.

Field Documentation

EventPair<EventHandle_WidgetSizeT, EventHandle_MultiListPtrSizeT> MyGUI::MultiListBox::eventListChangePosition

Event : Selected item position changed.
signature : void method(MyGUI::MultiListBox* _sender, size_t _index)

Parameters

_sender	widget that called this event
_index	of new item

Definition at line 278 of file MyGUI_MultiListBox.h.

EventPair<EventHandle_WidgetSizeT, EventHandle_MultiListPtrSizeT> MyGUI::MultiListBox::eventListSelectAccept

Event : Enter pressed or double click.
signature : void method(MyGUI::MultiListBox* _sender, size_t _index)

Parameters

_sender	widget that called this event
_index	of selected item

Definition at line 271 of file MyGUI_MultiListBox.h.

EventHandle_MultiListPtrSizeTCUTFStringRefCUTFStringRefBoolRef MyGUI::MultiListBox::requestOperatorLess

Event : Less than operator for sort multilist by columns.
signature : void method(MyGUI::MultiListBox* _sender, size_t _column, const MyGUI::UString& _firstItem, const MyGUI::UString& _secondItem, bool& _less)

Parameters

_sender	widget that called this event
_column	Index of column
_firstItem	Strings for compare
_secondItem	Strings for compare
_less	Comparsion result (write your value here)

Definition at line 288 of file MyGUI_MultiListBox.h.

The documentation for this class was generated from the following files:

Public Types

Public Member Functions

Static Public Member Functions

Data Fields

Protected Member Functions

Additional Inherited Members

Detailed Description

Member Typedef Documentation

Constructor & Destructor Documentation

Member Function Documentation

Field Documentation
