MyGUI: MyGUI::ISubWidget Class Reference

MyGUI 3.2.1

#include <MyGUI_ISubWidget.h>

Inheritance diagram for MyGUI::ISubWidget:

Public Types
typedef RTTIBase	Base

typedef ISubWidget	RTTIBase

Public Types inherited from MyGUI::IObject
typedef IObject	RTTIBase

Public Member Functions
virtual const std::string &	getTypeName () const

virtual bool	isType (const std::type_info &_type) const

template<typename Type >
bool	isType () const

	ISubWidget ()

virtual	~ISubWidget ()

virtual void	createDrawItem (ITexture _texture, ILayerNode _node)=0

virtual void	destroyDrawItem ()=0

virtual void	setAlpha (float _alpha)

virtual void	setStateData (IStateInfo *_data)

virtual void	doRender ()=0

virtual void	setAlign (Align _value)

virtual void	setVisible (bool _value)

virtual void	_updateView ()

virtual void	_correctView ()

virtual void	_setAlign (const IntSize &_oldsize)

virtual void	doManualRender (IVertexBuffer _buffer, ITexture _texture, size_t _count)

Public Member Functions inherited from MyGUI::ICroppedRectangle
	ICroppedRectangle ()

virtual	~ICroppedRectangle ()

ICroppedRectangle *	getCroppedParent ()

virtual void	setPosition (const IntPoint &_value)

virtual void	setSize (const IntSize &_value)

virtual void	setCoord (const IntCoord &_value)

IntPoint	getPosition () const

IntSize	getSize () const

const IntCoord &	getCoord () const

const IntPoint &	getAbsolutePosition () const

IntRect	getAbsoluteRect () const

IntCoord	getAbsoluteCoord () const

int	getAbsoluteLeft () const

int	getAbsoluteTop () const

int	getLeft () const

int	getRight () const

int	getTop () const

int	getBottom () const

int	getWidth () const

int	getHeight () const

bool	_isMargin () const

int	_getViewLeft () const

int	_getViewRight () const

int	_getViewTop () const

int	_getViewBottom () const

int	_getViewWidth () const

int	_getViewHeight () const

void	_setCroppedParent (ICroppedRectangle *_parent)

const IntRect &	_getMargin () const

int	_getMarginLeft () const

int	_getMarginRight () const

int	_getMarginTop () const

int	_getMarginBottom () const

Public Member Functions inherited from MyGUI::IObject
template<typename Type >
bool	isType () const

template<typename Type >
Type *	castType (bool _throw=true)

template<typename Type >
const Type *	castType (bool _throw=true) const

	IObject ()

virtual	~IObject ()

Static Public Member Functions
static const std::string &	getClassTypeName ()

Static Public Member Functions inherited from MyGUI::IObject
static const std::string &	getClassTypeName ()

Protected Attributes
Align	mAlign

bool	mVisible

Protected Attributes inherited from MyGUI::ICroppedRectangle
IntRect	mMargin

IntCoord	mCoord

IntPoint	mAbsolutePosition

bool	mIsMargin

ICroppedRectangle *	mCroppedParent

Additional Inherited Members
Protected Member Functions inherited from MyGUI::ICroppedRectangle
bool	_checkMargin ()

bool	_checkOutside () const

Detailed Description

Definition at line 24 of file MyGUI_ISubWidget.h.

Member Typedef Documentation

typedef RTTIBase MyGUI::ISubWidget::Base

Definition at line 28 of file MyGUI_ISubWidget.h.

typedef ISubWidget MyGUI::ISubWidget::RTTIBase

Definition at line 28 of file MyGUI_ISubWidget.h.

Constructor & Destructor Documentation

MyGUI::ISubWidget::ISubWidget ( )

inline

Definition at line 31 of file MyGUI_ISubWidget.h.

virtual MyGUI::ISubWidget::~ISubWidget ( )

inlinevirtual

Definition at line 32 of file MyGUI_ISubWidget.h.

Member Function Documentation

virtual void MyGUI::ISubWidget::_correctView ( )

inlinevirtual

Reimplemented in MyGUI::EditText, MyGUI::RotatingSkin, MyGUI::PolygonalSkin, MyGUI::SubSkin, and MyGUI::TileRect.

Definition at line 53 of file MyGUI_ISubWidget.h.

virtual void MyGUI::ISubWidget::_setAlign ( const IntSize & _oldsize )

inlinevirtual

Reimplemented in MyGUI::EditText, MyGUI::RotatingSkin, MyGUI::PolygonalSkin, MyGUI::SubSkin, MyGUI::TileRect, and MyGUI::MainSkin.

Definition at line 55 of file MyGUI_ISubWidget.h.

virtual void MyGUI::ISubWidget::_updateView ( )

inlinevirtual

Reimplemented in MyGUI::EditText, MyGUI::RotatingSkin, MyGUI::PolygonalSkin, MyGUI::SubSkin, and MyGUI::TileRect.

Definition at line 52 of file MyGUI_ISubWidget.h.

virtual void MyGUI::ISubWidget::createDrawItem	(	ITexture *	_texture,
		ILayerNode *	_node
	)

pure virtual

Implemented in MyGUI::EditText, MyGUI::RotatingSkin, MyGUI::PolygonalSkin, MyGUI::SubSkin, and MyGUI::TileRect.

virtual void MyGUI::ISubWidget::destroyDrawItem ( )

pure virtual

Implemented in MyGUI::EditText, MyGUI::RotatingSkin, MyGUI::PolygonalSkin, MyGUI::SubSkin, and MyGUI::TileRect.

virtual void MyGUI::ISubWidget::doManualRender	(	IVertexBuffer *	_buffer,
		ITexture *	_texture,
		size_t	_count
	)

inlinevirtual

Definition at line 57 of file MyGUI_ISubWidget.h.

virtual void MyGUI::ISubWidget::doRender ( )

pure virtual

Implemented in MyGUI::RotatingSkin, MyGUI::PolygonalSkin, MyGUI::SubSkin, MyGUI::EditText, MyGUI::TileRect, and MyGUI::SimpleText.

static const std::string& MyGUI::ISubWidget::getClassTypeName ( )

inlinestatic

Definition at line 28 of file MyGUI_ISubWidget.h.

virtual const std::string& MyGUI::ISubWidget::getTypeName ( ) const

inlinevirtual

Get type name as string

Reimplemented from MyGUI::IObject.

Reimplemented in MyGUI::EditText, MyGUI::SubSkin, MyGUI::TileRect, MyGUI::SimpleText, MyGUI::ISubWidgetText, MyGUI::PolygonalSkin, MyGUI::RotatingSkin, MyGUI::ISubWidgetRect, and MyGUI::MainSkin.

Definition at line 28 of file MyGUI_ISubWidget.h.

template<typename Type >

bool MyGUI::ISubWidget::isType ( ) const

inline

Compare with selected type

Definition at line 28 of file MyGUI_ISubWidget.h.

virtual bool MyGUI::ISubWidget::isType ( const std::type_info & _type ) const

inlinevirtual

Compare with selected type

Reimplemented from MyGUI::IObject.

Reimplemented in MyGUI::EditText, MyGUI::SubSkin, MyGUI::TileRect, MyGUI::SimpleText, MyGUI::ISubWidgetText, MyGUI::PolygonalSkin, MyGUI::RotatingSkin, MyGUI::ISubWidgetRect, and MyGUI::MainSkin.

Definition at line 28 of file MyGUI_ISubWidget.h.

virtual void MyGUI::ISubWidget::setAlign ( Align _value )

inlinevirtual

Definition at line 43 of file MyGUI_ISubWidget.h.

virtual void MyGUI::ISubWidget::setAlpha ( float _alpha )

inlinevirtual

Reimplemented in MyGUI::EditText, MyGUI::RotatingSkin, MyGUI::PolygonalSkin, MyGUI::SubSkin, and MyGUI::TileRect.

Definition at line 37 of file MyGUI_ISubWidget.h.

virtual void MyGUI::ISubWidget::setStateData ( IStateInfo * _data )

inlinevirtual

Reimplemented in MyGUI::EditText, MyGUI::RotatingSkin, MyGUI::TileRect, MyGUI::PolygonalSkin, and MyGUI::SubSkin.

Definition at line 39 of file MyGUI_ISubWidget.h.

virtual void MyGUI::ISubWidget::setVisible ( bool _value )

inlinevirtual

Reimplemented in MyGUI::RotatingSkin, MyGUI::PolygonalSkin, MyGUI::EditText, MyGUI::SubSkin, and MyGUI::TileRect.

Definition at line 47 of file MyGUI_ISubWidget.h.

Field Documentation

Align MyGUI::ISubWidget::mAlign

protected

Definition at line 60 of file MyGUI_ISubWidget.h.

bool MyGUI::ISubWidget::mVisible

protected

Definition at line 61 of file MyGUI_ISubWidget.h.

The documentation for this class was generated from the following file:

MyGUI_ISubWidget.h
