Canvas properties. Canvas_skin_childs Skin childs. Widget wrapper over Texture - shows the texture. Implemented: resizing of texture (see TextureResizeMode); recovery after loosing device; More...

#include <MyGUI_Canvas.h>

Inheritance diagram for MyGUI::Canvas:

Data Structures
struct	Event

Public Types
enum	TextureResizeMode { TRM_PT_CONST_SIZE, TRM_PT_VIEW_REQUESTED, TRM_PT_VIEW_ALL }

typedef RTTIBase	Base

typedef Canvas	RTTIBase

typedef delegates::CMultiDelegate1 < Canvas * >	EventHandle_CanvasPtr

typedef delegates::CDelegate2 < Canvas *, Event >	EventHandle_CanvasPtrEvent

Public Types inherited from MyGUI::Widget
typedef RTTIBase	Base

typedef Widget	RTTIBase

Public Types inherited from MyGUI::IObject
typedef IObject	RTTIBase

Public Member Functions
virtual const std::string &	getTypeName () const

virtual bool	isType (const std::type_info &_type) const

template<typename Type >
bool	isType () const

	Canvas ()

void	createTexture (TextureResizeMode _resizeMode, TextureUsage _usage=getDefaultTextureUsage(), PixelFormat _format=getDefaultTextureFormat())
	Creates texture. More...

void	createTexture (int _width, int _height, TextureResizeMode _resizeMode, TextureUsage _usage=getDefaultTextureUsage(), PixelFormat _format=getDefaultTextureFormat())
	Creates texture. More...

void	createTexture (const IntSize &_size, TextureResizeMode _resizeMode, TextureUsage _usage=getDefaultTextureUsage(), PixelFormat _format=getDefaultTextureFormat())
	Creates texture. More...

void	destroyTexture ()
	Destroys texture. More...

void	updateTexture ()
	Call user delegate update and removes old texture if it isn't original. More...

void *	lock (TextureUsage _usage=TextureUsage::Write)
	Locks hardware pixel buffer. More...

void	unlock ()
	Unlocks hardware pixel buffer. More...

bool	isLocked () const
	Checks lockness of hardware _pixel buffer. More...

int	getTextureRealWidth () const
	Returns real width of texture. More...

int	getTextureRealHeight () const
	Returns real height of texture. More...

IntSize	getTextureRealSize () const
	Returns real _size of texture. More...

int	getTextureSrcWidth () const
	Returns needed width while creating texture. More...

int	getTextureSrcHeight () const
	Returns needed height while creating texture. More...

IntSize	getTextureSrcSize () const
	Returns needed sizes while creating texture. More...

PixelFormat	getTextureFormat () const
	Returns needed sizes while creating texture. More...

const std::string &	getTextureName () const
	Returns name of the current texture. More...

virtual void	setSize (const IntSize &_value)
	More...

virtual void	setCoord (const IntCoord &_value)
	More...

void	setSize (int _width, int _height)
	More...

void	setCoord (int _left, int _top, int _width, int _height)
	More...

TextureResizeMode	getResizeMode () const
	Returns resize mode. More...

void	setResizeMode (TextureResizeMode _value)
	Sets resize mode of texture. More...

bool	isTextureSrcSize () const
	Checks if the texture has the source (required by user) size, otherwise real texture size are bigger. More...

bool	isTextureCreated () const
	Returns true if the texture was created (and exists), otherwise false. More...

bool	isTextureManaged () const
	Returns true if we own the texture, otherwise false. More...

ITexture *	getTexture () const
	Reurns interface texture. More...

void	setTextureManaged (bool _value)
	Sets the texture managed. More...

Public Member Functions inherited from MyGUI::Widget
template<typename Type >
bool	isType () const

	Widget ()

Widget *	createWidgetT (const std::string &_type, const std::string &_skin, const IntCoord &_coord, Align _align, const std::string &_name="")

Widget *	createWidgetT (const std::string &_type, const std::string &_skin, int _left, int _top, int _width, int _height, Align _align, const std::string &_name="")

Widget *	createWidgetRealT (const std::string &_type, const std::string &_skin, const FloatCoord &_coord, Align _align, const std::string &_name="")

Widget *	createWidgetRealT (const std::string &_type, const std::string &_skin, float _left, float _top, float _width, float _height, Align _align, const std::string &_name="")

template<typename T >
T *	createWidget (const std::string &_skin, const IntCoord &_coord, Align _align, const std::string &_name="")

template<typename T >
T *	createWidget (const std::string &_skin, int _left, int _top, int _width, int _height, Align _align, const std::string &_name="")

template<typename T >
T *	createWidgetReal (const std::string &_skin, const FloatCoord &_coord, Align _align, const std::string &_name="")

template<typename T >
T *	createWidgetReal (const std::string &_skin, float _left, float _top, float _width, float _height, Align _align, const std::string &_name="")

Widget *	createWidgetT (WidgetStyle _style, const std::string &_type, const std::string &_skin, const IntCoord &_coord, Align _align, const std::string &_layer="", const std::string &_name="")

template<typename T >
T *	createWidget (WidgetStyle _style, const std::string &_skin, const IntCoord &_coord, Align _align, const std::string &_layer="", const std::string &_name="")

virtual void	setPosition (const IntPoint &_value)

void	setPosition (int _left, int _top)

void	setSize (int _width, int _height)

void	setCoord (int _left, int _top, int _width, int _height)

void	setRealPosition (const FloatPoint &_value)

void	setRealSize (const FloatSize &_value)

void	setRealCoord (const FloatCoord &_value)

void	setRealPosition (float _left, float _top)

void	setRealSize (float _width, float _height)

void	setRealCoord (float _left, float _top, float _width, float _height)

const std::string &	getName () const
	Get name of widget. More...

virtual void	setVisible (bool _value)

bool	getVisible () const

void	setDepth (int _value)

int	getDepth () const

bool	getInheritedVisible () const

virtual void	setAlign (Align _value)

Align	getAlign () const

void	setAlpha (float _value)

float	getAlpha () const

void	setInheritsAlpha (bool _value)

bool	getInheritsAlpha () const

void	setColour (const Colour &_value)

bool	isRootWidget () const

Widget *	getParent () const

IntSize	getParentSize () const

EnumeratorWidgetPtr	getEnumerator () const

size_t	getChildCount ()

Widget *	getChildAt (size_t _index)

Widget *	findWidget (const std::string &_name)

void	findWidgets (const std::string &_name, VectorWidgetPtr &_result)

virtual void	setEnabled (bool _value)

void	setEnabledSilent (bool _value)

bool	getEnabled () const

bool	getInheritedEnabled () const

IntCoord	getClientCoord ()

Widget *	getClientWidget ()

void	detachFromWidget (const std::string &_layer="")

void	attachToWidget (Widget *_parent, WidgetStyle _style=WidgetStyle::Child, const std::string &_layer="")

void	changeWidgetSkin (const std::string &_skinName)

void	setWidgetStyle (WidgetStyle _style, const std::string &_layer="")

WidgetStyle	getWidgetStyle () const

void	setProperty (const std::string &_key, const std::string &_value)

virtual size_t	_getItemIndex (Widget *_item)

void	_forcePick (Widget *_widget)

void	_initialise (WidgetStyle _style, const IntCoord &_coord, const std::string &_skinName, Widget _parent, ICroppedRectangle _croppedParent, const std::string &_name)

void	_shutdown ()

void	_destroyChildWidget (Widget *_widget)

void	_setContainer (Widget *_value)

Widget *	_getContainer ()

void	_setAlign (const IntSize &_oldsize, const IntSize &_newSize)

bool	_checkPoint (int _left, int _top) const

Widget *	_createSkinWidget (WidgetStyle _style, const std::string &_type, const std::string &_skin, const IntCoord &_coord, Align _align, const std::string &_layer="", const std::string &_name="")

virtual void	_resetContainer (bool _update)

bool	_setWidgetState (const std::string &_value)

void	_updateChilds ()

Public Member Functions inherited from MyGUI::IObject
template<typename Type >
bool	isType () const

template<typename Type >
Type *	castType (bool _throw=true)

template<typename Type >
const Type *	castType (bool _throw=true) const

	IObject ()

virtual	~IObject ()

Public Member Functions inherited from MyGUI::ICroppedRectangle
	ICroppedRectangle ()

virtual	~ICroppedRectangle ()

ICroppedRectangle *	getCroppedParent ()

IntPoint	getPosition () const

IntSize	getSize () const

const IntCoord &	getCoord () const

const IntPoint &	getAbsolutePosition () const

IntRect	getAbsoluteRect () const

IntCoord	getAbsoluteCoord () const

int	getAbsoluteLeft () const

int	getAbsoluteTop () const

int	getLeft () const

int	getRight () const

int	getTop () const

int	getBottom () const

int	getWidth () const

int	getHeight () const

bool	_isMargin () const

int	_getViewLeft () const

int	_getViewRight () const

int	_getViewTop () const

int	_getViewBottom () const

int	_getViewWidth () const

int	_getViewHeight () const

void	_setCroppedParent (ICroppedRectangle *_parent)

const IntRect &	_getMargin () const

int	_getMarginLeft () const

int	_getMarginRight () const

int	_getMarginTop () const

int	_getMarginBottom () const

Public Member Functions inherited from MyGUI::UserData
	UserData ()

virtual	~UserData ()

void	setUserString (const std::string &_key, const std::string &_value)

const std::string &	getUserString (const std::string &_key) const

const MapString &	getUserStrings () const

bool	clearUserString (const std::string &_key)

bool	isUserString (const std::string &_key) const

void	clearUserStrings ()

void	setUserData (Any _data)

template<typename ValueType >
ValueType *	getUserData (bool _throw=true) const

void	_setInternalData (Any _data)

template<typename ValueType >
ValueType *	_getInternalData (bool _throw=true) const

Public Member Functions inherited from MyGUI::WidgetInput
	WidgetInput ()

virtual	~WidgetInput ()

void	setNeedToolTip (bool _value)

bool	getNeedToolTip () const

void	setPointer (const std::string &_value)

const std::string &	getPointer () const

void	setNeedKeyFocus (bool _value)

bool	getNeedKeyFocus () const

void	setNeedMouseFocus (bool _value)

bool	getNeedMouseFocus () const

void	setInheritsPick (bool _value)

bool	getInheritsPick () const

void	setMaskPick (const std::string &_filename)

void	setMaskPick (const MaskPickInfo &_info)

bool	isMaskPickInside (const IntPoint &_point, const IntCoord &_coord) const

bool	getRootMouseFocus () const

bool	getRootKeyFocus () const

void	_riseMouseLostFocus (Widget *_new)

void	_riseMouseSetFocus (Widget *_old)

void	_riseMouseDrag (int _left, int _top, MouseButton _id)

void	_riseMouseMove (int _left, int _top)

void	_riseMouseWheel (int _rel)

void	_riseMouseButtonPressed (int _left, int _top, MouseButton _id)

void	_riseMouseButtonReleased (int _left, int _top, MouseButton _id)

void	_riseMouseButtonClick ()

void	_riseMouseButtonDoubleClick ()

void	_riseKeyLostFocus (Widget *_new)

void	_riseKeySetFocus (Widget *_old)

void	_riseKeyButtonPressed (KeyCode _key, Char _char)

void	_riseKeyButtonReleased (KeyCode _key)

void	_riseMouseChangeRootFocus (bool _focus)

void	_riseKeyChangeRootFocus (bool _focus)

void	_setRootMouseFocus (bool _value)

void	_setRootKeyFocus (bool _value)

Public Member Functions inherited from MyGUI::delegates::IDelegateUnlink
virtual	~IDelegateUnlink ()

	IDelegateUnlink ()

bool	compare (IDelegateUnlink *_unlink) const

Public Member Functions inherited from MyGUI::SkinItem
	SkinItem ()

ISubWidgetText *	getSubWidgetText ()

ISubWidgetRect *	getSubWidgetMain ()

void	_setTextureName (const std::string &_texture)

const std::string &	_getTextureName () const

Public Member Functions inherited from MyGUI::LayerItem
	LayerItem ()

virtual	~LayerItem ()

ILayer *	getLayer () const

ILayerNode *	getLayerNode () const

virtual void	attachItemToNode (ILayer _layer, ILayerNode _node)

virtual void	detachFromLayer ()

virtual void	upLayerItem ()

void	setRenderItemTexture (ITexture *_texture)

void	addChildItem (LayerItem *_item)

void	removeChildItem (LayerItem *_item)

void	addChildNode (LayerItem *_item)

void	removeChildNode (LayerItem *_item)

void	addRenderItem (ISubWidget *_item)

void	removeAllRenderItems ()

void	saveLayerItem ()

void	restoreLayerItem ()

Public Member Functions inherited from MyGUI::ILayerItem
virtual	~ILayerItem ()

Public Member Functions inherited from MyGUI::MemberObsolete< Widget >
bool	isEnabled ()

bool	isInheritsAlpha ()

bool	isNeedKeyFocus ()

bool	isNeedMouseFocus ()

bool	isInheritsPick ()

bool	isVisible ()

Public Member Functions inherited from MyGUI::ITextureInvalidateListener
virtual	~ITextureInvalidateListener ()

Static Public Member Functions
static const std::string &	getClassTypeName ()

static TextureUsage	getDefaultTextureUsage ()
	Returns default GUI texture usage. More...

static PixelFormat	getDefaultTextureFormat ()
	Returns default GUI texture format. More...

Static Public Member Functions inherited from MyGUI::Widget
static const std::string &	getClassTypeName ()

Static Public Member Functions inherited from MyGUI::IObject
static const std::string &	getClassTypeName ()

Data Fields
EventHandle_CanvasPtr	eventPreTextureChanges

EventHandle_CanvasPtrEvent	requestUpdateCanvas

Data Fields inherited from MyGUI::Widget
EventHandle_WidgetStringString	eventChangeProperty

EventHandle_WidgetVoid	eventChangeCoord

Data Fields inherited from MyGUI::WidgetInput
EventHandle_WidgetWidget	eventMouseLostFocus

EventHandle_WidgetWidget	eventMouseSetFocus

EventPairAddParameter < EventHandle_WidgetIntInt, EventHandle_WidgetIntIntButton >	eventMouseDrag

EventHandle_WidgetIntInt	eventMouseMove

EventHandle_WidgetInt	eventMouseWheel

EventHandle_WidgetIntIntButton	eventMouseButtonPressed

EventHandle_WidgetIntIntButton	eventMouseButtonReleased

EventHandle_WidgetVoid	eventMouseButtonClick

EventHandle_WidgetVoid	eventMouseButtonDoubleClick

EventHandle_WidgetWidget	eventKeyLostFocus

EventHandle_WidgetWidget	eventKeySetFocus

EventHandle_WidgetKeyCodeChar	eventKeyButtonPressed

EventHandle_WidgetKeyCode	eventKeyButtonReleased

EventHandle_WidgetBool	eventRootMouseChangeFocus

EventHandle_WidgetBool	eventRootKeyChangeFocus

EventHandle_WidgetToolTip	eventToolTip

Protected Member Functions
virtual void	shutdownOverride ()

virtual void	initialiseOverride ()

void	_destroyTexture (bool _sendEvent)
	Destroys texture. More...

void	validate (int &_width, int &_height, TextureUsage &_usage, PixelFormat &_format) const
	Update entered parameters according to current texture resize mode(size) and restore (if can) parameters of usage and format from texture. More...

void	createExactTexture (int _width, int _height, TextureUsage _usage, PixelFormat _format)
	Creates the texture itself. More...

bool	checkCreate (int _width, int _height) const
	Checks if we need to create a texture with such sizes. More...

void	resize (const IntSize &_size)
	Calls when resize widget. More...

void	correctUV ()
	Correct texture uv-coordinates. More...

void	frameAdvise (bool _advise)
	For updating once per frame. More...

void	frameEntered (float _time)
	For updating once per frame. More...

virtual void	textureInvalidate (ITexture *_texture)

void	_setUVSet (const FloatRect &_rect)

Protected Member Functions inherited from MyGUI::Widget
virtual	~Widget ()

void	_updateView ()

Widget *	baseCreateWidget (WidgetStyle _style, const std::string &_type, const std::string &_skin, const IntCoord &_coord, Align _align, const std::string &_layer, const std::string &_name, bool _template)

void	_destroyAllChildWidget ()

virtual size_t	_getContainerIndex (const IntPoint &_point)

virtual void	baseUpdateEnable ()

virtual ILayerItem *	getLayerItemByPoint (int _left, int _top) const

virtual const IntCoord &	getLayerItemCoord () const

template<typename T >
void	assignWidget (T *&_widget, const std::string &_name)

VectorWidgetPtr	getSkinWidgetsByName (const std::string &_name)

void	destroySkinWidget (Widget *_widget)

virtual void	onWidgetCreated (Widget *_widget)

virtual void	onWidgetDestroy (Widget *_widget)

void	setWidgetClient (Widget *_widget)

virtual void	setPropertyOverride (const std::string &_key, const std::string &_value)

Protected Member Functions inherited from MyGUI::ICroppedRectangle
bool	_checkMargin ()

bool	_checkOutside () const

Protected Member Functions inherited from MyGUI::WidgetInput
virtual void	onMouseLostFocus (Widget *_new)

virtual void	onMouseSetFocus (Widget *_old)

virtual void	onMouseDrag (int _left, int _top, MouseButton _id)

virtual void	onMouseMove (int _left, int _top)

virtual void	onMouseWheel (int _rel)

virtual void	onMouseButtonPressed (int _left, int _top, MouseButton _id)

virtual void	onMouseButtonReleased (int _left, int _top, MouseButton _id)

virtual void	onMouseButtonClick ()

virtual void	onMouseButtonDoubleClick ()

virtual void	onKeyLostFocus (Widget *_new)

virtual void	onKeySetFocus (Widget *_old)

virtual void	onKeyButtonPressed (KeyCode _key, Char _char)

virtual void	onKeyButtonReleased (KeyCode _key)

virtual void	onMouseChangeRootFocus (bool _focus)

virtual void	onKeyChangeRootFocus (bool _focus)

Protected Member Functions inherited from MyGUI::SkinItem
void	_createSkinItem (ResourceSkin *_info)

void	_deleteSkinItem ()

void	_setSkinItemAlign (const IntSize &_size)

void	_setSkinItemVisible (bool _value)

void	_setSkinItemColour (const Colour &_value)

void	_setSkinItemAlpha (float _value)

void	_correctSkinItemView ()

void	_updateSkinItemView ()

bool	_setSkinItemState (const std::string &_state)

void	_setSubSkinVisible (bool _visible)

Protected Member Functions inherited from MyGUI::LayerItem
void	attachToLayerItemNode (ILayerNode *_node, bool _deep)

void	detachFromLayerItemNode (bool _deep)

Protected Attributes
ITexture *	mTexture
	Current texture. More...

IntSize	mReqTexSize
	Requested bu user sizes. More...

std::string	mGenTexName
	Generated texture name. More...

TextureResizeMode	mTexResizeMode
	Texture resize mode. More...

uint8 *	mTexData
	Saved pointer from last calling lock. More...

bool	mTexManaged
	true if we own the texture (can delete it or replace by another instance), otherwise false More...

bool	mFrameAdvise
	For updating once per frame. True state means updating before next frame starts. More...

bool	mInvalidateData

Detailed Description

Canvas properties. Canvas_skin_childs Skin childs. Widget wrapper over Texture - shows the texture. Implemented: resizing of texture (see TextureResizeMode); recovery after loosing device;

Definition at line 21 of file MyGUI_Canvas.h.

Member Typedef Documentation

typedef RTTIBase MyGUI::Canvas::Base

Definition at line 25 of file MyGUI_Canvas.h.

typedef delegates::CMultiDelegate1<Canvas*> MyGUI::Canvas::EventHandle_CanvasPtr

Definition at line 46 of file MyGUI_Canvas.h.

typedef delegates::CDelegate2<Canvas*, Event> MyGUI::Canvas::EventHandle_CanvasPtrEvent

Definition at line 47 of file MyGUI_Canvas.h.

typedef Canvas MyGUI::Canvas::RTTIBase

Definition at line 25 of file MyGUI_Canvas.h.

Member Enumeration Documentation

enum MyGUI::Canvas::TextureResizeMode

Available resize and view modes of texture

Remarks: PT - Power of Two (size)

Enumerator

TRM_PT_CONST_SIZE

Mode when the texture has constant size and stretching on all widget.

Remarks: The size specified at creation of the texture increases to nearest power of two and doesn't change any more. Texture is always stretched on all widget.

TRM_PT_VIEW_REQUESTED

Mode when texture pixels look as is.

Remarks: The texture size is always more or equal than the widget size and is equal to a power of two.

Note: The size specified at creation of the texture is ignored. The texture is automatically recreated if the size of the widget becomes bigger.

TRM_PT_VIEW_ALL

Mode when the texture stretched on all widget and automatically changes the size for nice look.

Remarks: The mode same as TRM_PT_VIEW_REQUESTED, but the texture is scaled till the size of the widget.

Note: The size specified at creation of the texture is ignored. The texture is automatically recreated if the size of the widget becomes bigger.

Definition at line 53 of file MyGUI_Canvas.h.

Constructor & Destructor Documentation

MyGUI::Canvas::Canvas ( )

Definition at line 17 of file MyGUI_Canvas.cpp.

Member Function Documentation

void MyGUI::Canvas::_destroyTexture ( bool _sendEvent )

protected

Destroys texture.

Definition at line 162 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::_setUVSet ( const FloatRect & _rect )

protected

Definition at line 268 of file MyGUI_Canvas.cpp.

bool MyGUI::Canvas::checkCreate	(	int	_width,
		int	_height
	)		const

protected

Checks if we need to create a texture with such sizes.

Definition at line 117 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::correctUV ( )

protected

Correct texture uv-coordinates.

Definition at line 177 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::createExactTexture	(	int	_width,
		int	_height,
		TextureUsage	_usage,
		PixelFormat	_format
	)

protected

Creates the texture itself.

Definition at line 44 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::createTexture	(	TextureResizeMode	_resizeMode,
		TextureUsage	_usage = `getDefaultTextureUsage()`,
		PixelFormat	_format = `getDefaultTextureFormat()`
	)

Creates texture.

Definition at line 28 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::createTexture	(	int	_width,
		int	_height,
		TextureResizeMode	_resizeMode,
		TextureUsage	_usage = `getDefaultTextureUsage()`,
		PixelFormat	_format = `getDefaultTextureFormat()`
	)

Creates texture.

Definition at line 72 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::createTexture	(	const IntSize &	_size,
		TextureResizeMode	_resizeMode,
		TextureUsage	_usage = `getDefaultTextureUsage()`,
		PixelFormat	_format = `getDefaultTextureFormat()`
	)

Creates texture.

Definition at line 36 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::destroyTexture ( )

Destroys texture.

Definition at line 147 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::frameAdvise ( bool _advise )

protected

For updating once per frame.

Definition at line 214 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::frameEntered ( float _time )

protected

For updating once per frame.

Definition at line 234 of file MyGUI_Canvas.cpp.

static const std::string& MyGUI::Canvas::getClassTypeName ( )

inlinestatic

Definition at line 25 of file MyGUI_Canvas.h.

PixelFormat MyGUI::Canvas::getDefaultTextureFormat ( )

static

Returns default GUI texture format.

Definition at line 364 of file MyGUI_Canvas.cpp.

TextureUsage MyGUI::Canvas::getDefaultTextureUsage ( )

static

Returns default GUI texture usage.

Definition at line 359 of file MyGUI_Canvas.cpp.

Canvas::TextureResizeMode MyGUI::Canvas::getResizeMode ( ) const

Returns resize mode.

Definition at line 329 of file MyGUI_Canvas.cpp.

ITexture * MyGUI::Canvas::getTexture ( ) const

Reurns interface texture.

Definition at line 349 of file MyGUI_Canvas.cpp.

PixelFormat MyGUI::Canvas::getTextureFormat ( ) const

Returns needed sizes while creating texture.

Definition at line 309 of file MyGUI_Canvas.cpp.

const std::string & MyGUI::Canvas::getTextureName ( ) const

Returns name of the current texture.

Definition at line 314 of file MyGUI_Canvas.cpp.

int MyGUI::Canvas::getTextureRealHeight ( ) const

Returns real height of texture.

Definition at line 284 of file MyGUI_Canvas.cpp.

IntSize MyGUI::Canvas::getTextureRealSize ( ) const

Returns real _size of texture.

Definition at line 289 of file MyGUI_Canvas.cpp.

int MyGUI::Canvas::getTextureRealWidth ( ) const

Returns real width of texture.

Definition at line 279 of file MyGUI_Canvas.cpp.

int MyGUI::Canvas::getTextureSrcHeight ( ) const

Returns needed height while creating texture.

Definition at line 299 of file MyGUI_Canvas.cpp.

IntSize MyGUI::Canvas::getTextureSrcSize ( ) const

Returns needed sizes while creating texture.

Definition at line 304 of file MyGUI_Canvas.cpp.

int MyGUI::Canvas::getTextureSrcWidth ( ) const

Returns needed width while creating texture.

Definition at line 294 of file MyGUI_Canvas.cpp.

virtual const std::string& MyGUI::Canvas::getTypeName ( ) const

inlinevirtual

Get type name as string

Reimplemented from MyGUI::Widget.

Definition at line 25 of file MyGUI_Canvas.h.

void MyGUI::Canvas::initialiseOverride ( )

protectedvirtual

Reimplemented from MyGUI::Widget.

Definition at line 158 of file MyGUI_Canvas.cpp.

bool MyGUI::Canvas::isLocked ( ) const

Checks lockness of hardware _pixel buffer.

Definition at line 274 of file MyGUI_Canvas.cpp.

bool MyGUI::Canvas::isTextureCreated ( ) const

Returns true if the texture was created (and exists), otherwise false.

Definition at line 339 of file MyGUI_Canvas.cpp.

bool MyGUI::Canvas::isTextureManaged ( ) const

Returns true if we own the texture, otherwise false.

See Also: mManaged

Definition at line 344 of file MyGUI_Canvas.cpp.

bool MyGUI::Canvas::isTextureSrcSize ( ) const

Checks if the texture has the source (required by user) size, otherwise real texture size are bigger.

Definition at line 209 of file MyGUI_Canvas.cpp.

virtual bool MyGUI::Canvas::isType ( const std::type_info & _type ) const

inlinevirtual

Compare with selected type

Reimplemented from MyGUI::Widget.

Definition at line 25 of file MyGUI_Canvas.h.

template<typename Type >

bool MyGUI::Canvas::isType ( ) const

inline

Compare with selected type

Definition at line 25 of file MyGUI_Canvas.h.

void * MyGUI::Canvas::lock ( TextureUsage _usage = TextureUsage::Write )

Locks hardware pixel buffer.

Definition at line 195 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::resize ( const IntSize & _size )

protected

Calls when resize widget.

Definition at line 62 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::setCoord ( const IntCoord & _value )

virtual

Set widget position and size

Reimplemented from MyGUI::Widget.

Definition at line 104 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::setCoord	(	int	_left,
		int	_top,
		int	_width,
		int	_height
	)

See Widget::setCoord(const IntCoord& _coord)

Definition at line 324 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::setResizeMode ( TextureResizeMode _value )

Sets resize mode of texture.

See Also: TextureResizeMode

Definition at line 334 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::setSize ( const IntSize & _value )

virtual

Set widget size

Reimplemented from MyGUI::Widget.

Definition at line 97 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::setSize	(	int	_width,
		int	_height
	)

See Widget::setSize(const IntSize& _size)

Definition at line 319 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::setTextureManaged ( bool _value )

Sets the texture managed.

Remarks: Be careful with assigning managed status to texture, which wasn't created in Canvas!

See Also: mManaged

Definition at line 354 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::shutdownOverride ( )

protectedvirtual

Reimplemented from MyGUI::Widget.

Definition at line 152 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::textureInvalidate ( ITexture * _texture )

protectedvirtual

Implements MyGUI::ITextureInvalidateListener.

Definition at line 263 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::unlock ( )

Unlocks hardware pixel buffer.

Definition at line 204 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::updateTexture ( )

Call user delegate update and removes old texture if it isn't original.

Definition at line 111 of file MyGUI_Canvas.cpp.

void MyGUI::Canvas::validate	(	int &	_width,
		int &	_height,
		TextureUsage &	_usage,
		PixelFormat &	_format
	)		const

protected

Update entered parameters according to current texture resize mode(size) and restore (if can) parameters of usage and format from texture.

Definition at line 128 of file MyGUI_Canvas.cpp.

Field Documentation

EventHandle_CanvasPtr MyGUI::Canvas::eventPreTextureChanges

Event : Notify user texture instance will be changed

See Also: requestUpdateCanvas.
signature : void method(MyGUI::Canvas* _canvas)

Parameters

_canvas,which will be updated

Definition at line 182 of file MyGUI_Canvas.h.

bool MyGUI::Canvas::mFrameAdvise

protected

For updating once per frame. True state means updating before next frame starts.

Definition at line 243 of file MyGUI_Canvas.h.

std::string MyGUI::Canvas::mGenTexName

protected

Generated texture name.

Definition at line 231 of file MyGUI_Canvas.h.

bool MyGUI::Canvas::mInvalidateData

protected

Definition at line 245 of file MyGUI_Canvas.h.

IntSize MyGUI::Canvas::mReqTexSize

protected

Requested bu user sizes.

Definition at line 228 of file MyGUI_Canvas.h.

uint8* MyGUI::Canvas::mTexData

protected

Saved pointer from last calling lock.

See Also: lock

Definition at line 237 of file MyGUI_Canvas.h.

bool MyGUI::Canvas::mTexManaged

protected

true if we own the texture (can delete it or replace by another instance), otherwise false

Definition at line 240 of file MyGUI_Canvas.h.

TextureResizeMode MyGUI::Canvas::mTexResizeMode

protected

Texture resize mode.

See Also: TextureResizeMode

Definition at line 234 of file MyGUI_Canvas.h.

ITexture* MyGUI::Canvas::mTexture

protected

Current texture.

Definition at line 225 of file MyGUI_Canvas.h.

EventHandle_CanvasPtrEvent MyGUI::Canvas::requestUpdateCanvas

Event : Texture instance was changed (May be caused by resizing texture or lossing device). User have to update all references to new instance of texture.
signature : void method(MyGUI::Canvas* _canvas, MyGUI::Canvas::Event _event)

Parameters

_canvas,which	needs to update
_event

Definition at line 189 of file MyGUI_Canvas.h.

The documentation for this class was generated from the following files:

Data Structures

Public Types

Public Member Functions

Static Public Member Functions

Data Fields

Protected Member Functions

Protected Attributes

Detailed Description

Member Typedef Documentation

Member Enumeration Documentation

Constructor & Destructor Documentation

Member Function Documentation

Field Documentation
